The HES 9400 Electric Strike is a slim-line, surface-mounted solution designed for rim exit devices with a 1/2″ Pullman latch; It offers outdoor-rated durability, easy installation without frame cutting, and meets Grade 1 standards for strength and reliability, making it a trusted choice for secure access control systems.

Overview of the HES 9400 Series

The HES 9400 Series is a line of electric strikes designed for seamless integration with rim exit devices, offering a robust and reliable solution for access control systems. These strikes are part of the broader HES product family, which includes models like the 9500, 9600, and 9700, all known for their durability and versatility. The 9400 Series is engineered to accommodate rim exit devices with a 1/2″ Pullman latchbolt, making it suitable for a wide range of commercial and industrial applications. Its surface-mounted design eliminates the need for frame cutting, simplifying installation on both metal and wood door frames. The series is built with outdoor-rated components, ensuring resilience in harsh environments. Additionally, the 9400 Series strikes are shipped with a 1/8″ spacer plate to address varying door gaps, and they support field-selectable operation modes, including fail secure and fail safe; This adaptability, combined with a sleek design and Grade 1 strength rating, makes the HES 9400 Series a preferred choice for secure and efficient access control solutions.

Importance of the HES 9400 Electric Strike in Access Control

The HES 9400 Electric Strike plays a pivotal role in modern access control systems by providing a secure, reliable, and adaptable solution for managing entry points. Its ability to integrate seamlessly with rim exit devices ensures that it can be used in a variety of settings, from commercial buildings to industrial facilities. The strike’s durability and outdoor-rated design make it suitable for harsh environments, ensuring consistent performance regardless of conditions. By offering field-selectable fail secure and fail safe operation modes, the HES 9400 caters to different security requirements, making it a versatile option for access control needs. Its compatibility with 12VDC or 24VDC power supplies further enhances its scalability and ease of integration into existing systems. This strike is essential for ensuring secure access control while maintaining ease of use and reliability, making it a critical component in modern security infrastructure.

Key Features and Benefits of the HES 9400

• Field-selectable fail secure or fail safe operation for flexible security needs.
• Compatibility with rim exit devices up to 1/2″ Pullman latchbolt.
• Adjustable spacer plate for varying door gaps, ensuring proper alignment.
• No frame cutting required for easy installation on metal or wood frames.
• Meets Grade 1 standards for strength and durability.
• Sleek cover conceals mounting screws for a clean appearance.

Field-Selectable Fail Secure/Fail Safe Operation

The HES 9400 Electric Strike offers field-selectable fail secure and fail safe operation, providing flexibility for different security and safety requirements. Fail secure mode keeps the strike locked when de-energized, ensuring security in the event of a power failure. Fail safe mode unlocks the strike when power is lost, which is critical for emergency egress in fire or windstorm-rated applications. The strike ships pre-set to fail secure operation but can be easily converted to fail safe if needed. This feature allows installers to adapt the strike to specific application needs without additional components. The ability to select operation modes ensures the HES 9400 can meet a wide range of access control demands while maintaining reliability and performance. This flexibility, combined with its robust design, makes it a versatile solution for secure and safe door control systems.

Compatibility with Rim Exit Devices

The HES 9400 Electric Strike is specifically designed to work seamlessly with rim exit devices, accommodating latchbolts up to a 1/2″ Pullman latch. Its slim-line, surface-mounted design ensures compatibility with a wide range of exit hardware, making it a versatile solution for access control systems. The strike is compatible with both metal and wood door frames, eliminating the need for costly modifications. An adjustable spacer plate is included to ensure proper alignment and clearance, regardless of door gap variations. This feature enhances reliability and ensures smooth operation with various rim exit devices. The HES 9400 is part of the 9400 Series, which includes models like the 9500, 9600, and 9700, all designed to integrate with existing door hardware seamlessly. Its compatibility with standard rim exit devices makes it a preferred choice for secure and efficient access control solutions in commercial and industrial settings.

Adjustable Spacer Plate for Varying Door Gaps

The HES 9400 Electric Strike includes an adjustable spacer plate to accommodate varying door gaps, ensuring proper alignment and clearance. This feature eliminates the need for additional accessories, as the spacer plate is designed to fit seamlessly with different door configurations. The 9400 series ships with a 1/8″ spacer plate, which can be adjusted to ensure optimal engagement with the latchbolt. For units ordered in a 630 finish, the spacer plate is stainless steel, while other finishes include a black stainless steel spacer. This adaptability makes the HES 9400 suitable for a wide range of door frames, including metal and wood. The adjustable spacer plate enhances installation efficiency and ensures reliable operation, regardless of door gap variations. This feature is particularly beneficial in environments where door frames may shift or settle over time, maintaining consistent performance and security.

Installation and Setup of the HES 9400

The HES 9400 installation is straightforward, requiring no frame cutting. It aligns with the exit latchbolt and secures with mounting screws, fitting both metal and wood door frames effortlessly, ensuring quick setup.

Step-by-Step Installation Guide

Mount the Strike: Place the HES 9400 on the door frame, aligning it with the exit latchbolt. Secure it using the provided 1/4-20 x 1 mounting screws. No frame cutting is required.

Adjust Spacer Plate: The strike comes with a 1/8″ spacer plate. If needed, additional spacers can be ordered to accommodate varying door gaps.

Connect Wiring: The HES 9400 operates on 12VDC or 24VDC. Refer to the wiring diagram for proper connections. Ensure the power source matches the selected voltage.

Set Operation Mode: The strike defaults to Fail Secure mode. To switch to Fail Safe, follow the conversion instructions in the manual.

Test Operation: Verify that the latchbolt engages smoothly with the strike. Check all electrical connections to ensure proper functionality.

By following these steps, the HES 9400 is efficiently installed, ensuring reliable access control for your doors.

Frame Preparation Requirements

The HES 9400 Electric Strike requires minimal frame preparation, as it is designed for surface mounting without the need for cutting or modifications. Ensure the door frame is compatible with the strike’s mounting pattern and can support the weight and functionality of the unit. The strike is compatible with both metal and wood door frames, making it versatile for various applications. Before installation, verify that the frame is clean and free of obstructions to ensure proper alignment with the rim exit device. The HES 9400 includes all necessary hardware, such as mounting screws, to secure it to the frame. No additional framing adjustments are required, allowing for a streamlined installation process. This design ensures compatibility and ease of use, making the HES 9400 a convenient solution for access control systems.

Wiring and Voltage Considerations

The HES 9400 Electric Strike is designed to operate with either 12VDC or 24VDC, offering flexibility in power supply configurations. It is important to ensure the voltage supply matches the strike’s rating to avoid damage. The unit is pre-wired with red and green wires for status indication, simplifying installation. For fail-safe operation, a diode (1N4007) must be connected in parallel with the solenoid to prevent voltage spikes. The strike’s wiring setup supports both fail-secure and fail-safe modes, depending on the application requirements. Proper wiring is essential to maintain the product’s warranty and ensure reliable performance. Always refer to the installation manual for specific wiring diagrams and instructions. The HES 9400’s dual-voltage capability makes it adaptable to various access control systems, but it is crucial to adhere to the specified voltage constraints to prevent damage and ensure optimal functionality.
